SUB215 to Debut at InfoComm



The New SUB215 is a compact, fast-RESPONDING, and deep subwoofer. Officially launching this June at InfoCOmm!

The SUB215 is a fast-responding, deep bass subwoofer capable of producing a maximum SPL of 140 dB. This cabinet is equipped with (2) 15” low frequency drivers with the newest tetracoil technology. This Subwoofer is deep but also delivers clear & punchy upper bass. The SUB215 cabinet is only 17.8” wide when deployed vertically or 17.8” tall when deployed horizontally.

Use the SUB215 as a completed system utilizing the pole cup accessory which allows you to deploy the CT28 with a 1 SOUND Active Tube or mount any other satellite on top. In addition, this subwoofer has proprietary rigging points in order to attach a Tower Rigging System, fit for stacking the Tower LCC44 or LCC84 on top.

Like all 1 SOUND loudspeakers, the SUB215 is IP55 rated and saltwater resistant with custom colors and finishes available.




Be the first to hear the SUB215 as well as the new Contour CT212 at InfoComm in the 1 SOUND Demo Room!
Demo Room: W221A
Booth:5669




SPECIFICATIONS

Description:    passive, fast-responding, powerful, deep, and loud
Bandwidth:    30 Hz - 120 Hz (-6 dB preset dependent)
Max SPL:    140 dB @ 1m with preset
Power:    3600 watts  (program), 1800 watts (AES)
Directivity:    omnidirectional
Elements :    (2) 15” tetracoil technology low frequency drivers
Impedance:   4 Ω
Connectors:    (2) NL4
IP Rating:    IP55 indoor/outdoor and salt water resistant
Rigging:     16 rigging points
Weight:   133.8 lbs / 60.7 kg
Construction:    Finland birch plywood (urea glue), matte salt and UV resistant coating, 316 stainless steel hardware, 3D spacer mesh fabric
Accessories:     Sub Pole Cup, Tower Rigging System, detachable wheels for easy transport, removable rubber feet
Dimensions:    37.4” (950 mm) x 17.7” (450 mm) x 26.7” (680 mm)
Colors:    Stocking black and white, custom colors and fabrics available
